Features

Easy air low-air-loss and alternating pressure for patients weighing up to 1000 lbs

Easy air low-air-loss design is documented best among leading low air loss systems and is accessible to bariatric patients in the PressureGuard Easy Air® XL

Multiple advantages of the PressureGuard design prevent skin maceration, and adequately reduce the effects of pressure, shearing, friction, and heat buildup

Additional Advantages:

Will not lose inflation, even during power outages

Stable surface is specifically designed to not "swallow up" the patient

Outer Removable Coverlet:

Fluid proof, flame resistant, and very easy to clean

Highly vapor permeable (4500 grams/meter2/24 hours)

Smooth top fabric and crush-proof air diffusion matrix fabrics are bacteriostatic and able to maintain pathways for air flow, even under the heaviest patient weights

Can either be routinely wiped clean and disinfected in place, or removed and machine laundered according to owner’s manual

Inner Air-Delivery Cover:

Multi-layered cover supplies air to microenvironment between cover and coverlet

Serves as a barrier to protect inside of mattress from both fluids and vapors

Foam Shell – Exclusive Geo-Matt Style Foam Topper:

High density medical grade foam

Unique geometric design consists of over 800 individual cells to customize comfort, support, pressure reduction and pressure redistribution for each patient

2" height includes unique Heel Slope™ feature designed to reduce pressure for the sensitive heel area

Safety Edge™ Bolsters:

Inner edges of the firm 2-part foam bolster contour under pressure and direct the patient towards the center of the mattress

Resists compression and increases patient safety

Increases patient stability in both sitting and lying down positions

Helps prevent falls and entrapment between the side rail and mattress

Air Cylinders:

Inflation system consists of four air cylinders that run lengthwise underneath the body

Does not lose air from the inflation system for "low air loss"

Can be programmed to perform either “flotation” or “alternating pressure”

Control Unit:

The quiet energy efficient control unit houses both a high volume air blower and a lower volume air pump

Blower component provides air for the low air loss function through the cover/coverlet

Pump component provides air to the air-cylinder inflation system

Filters on control unit should be cleaned regularly

Sizes

42 x 80 x 7: SAB-APM42807-750

48 x 80 x 7: SAB-APM48807-750

54 x 80 x 7: SAB-APM54807-750

42 x 84 x 7: SAB-APM42847-750

48 x 84 x 7: SAB-APM48847-750

54 x 84 x 7: SAB-APM54847-750

Weight Capacity

750 lbs.

Warranty

18 months non-prorated

Replacement Cover

Replaceable Cover: Bacteriostatic top fabric is fire resistant, fluid proof, tear resistant, and easy to clean Pleated design allows for full integration with the mattress’ Geo-Matt style shear-relieving surface while also minimizing hammocking
